2013 Buell 1190RS
2013 Buell 1190RS

The 2013 Buell 1190RS is the flagship sport motorcycle of Buell. It is equipped with a Liquid cooled V twin 1190 CC engine producing
175 hp @ 9750 rpm and 131.5 Nm of torque @ 9750 rpm. it’s frame chassis is made of aluminum, it features a Öhlins fully adjustable suspension on the rear wheel and a 43 mm Öhlins inverted fork with adjustable compression damping at the front.

It has a seat height of 775 mm, a fuel tank of 17.1 liters and it’s dry weight is 176 kg. It is available in two colors: Pitch Black and Carbon. It’s starting price is at $41,995 and if you want the carbon package you will have to pay $4,000 more.

SPECIFICATIONS

ENGINE

Type Liquid cooled V twin
Bore X Stroke 4.17 x 2.66 (106 x 67.5 mm)
Displacement 72.6 cu 1190 CC
Compression Ratio 13.6 :1
Fuel Delivery Dual 61mm throttle bodies
Exhaust Primary + Secondary
Peak Torque 97 ft-lbs @ 9400 rpm
Peak Horsepower 175 hp @ 9750 rpm

DRIVETRAIN

Primary Drive Gear, 36/65
Final Drive 520 Chain, 16/41
Clutch Wet multi-plate, slipper
Transmission Ratios:
1st 2.46
2nd 1.75
3rd 1.38
4th 1.17
5th 1.04
6th 0.96

DIMENSIONS

Seat Height 30.5″ (775 mm)
Rake 22
Trail 3.4″ (86 mm)
Lean Angle 55
Front Tire 120/70R- 17
Rear Tire 190/55R-17
Fuel Capacity 4.5 gal (17.1 L)
Wet Weight (No Fuel) 389 lbs (176 kg)

CHASSIS

Frame Aluminum frame with integral fuel reservoir
Swingarm Optimized stiffness aluminum
Front Suspension 43 mm Öhlins inverted fork, adjustable compression damping, rebound damping adjustable spring preload
Rear Suspension Öhlins fully adjustable TTX coil over monoshock with remote reservoir
Front Wheel 3.5″ x 17″ magnesium
Rear Wheel 6.0″ x 17″ magnesium
Front Brake ISO finned rotor, 8 piston caliper with cooling duct

2013 EBR RS

MSRP $41,995
Carbon Package Add $4,000
Colors
Carbon and Pitch Black
