2014 Husqvarna TE 250
2014 Husqvarna TE 250

The 2014 Husqvarna TE 250 is equipped with a 1-cylinder, 2-stroke, water-cooled engine of 249 cc combined with a 6 gear transmission. It features a 48mm WP 4CS front fork, an adjustable rear shock suspension, 260 mm brake discs on the front and 220 mm brake disks on the rear.

It has a ground clearance of 355 mm, a seat height of 960 mm, a fuel tank of 11 liters and it weighs 104.4 kilos.

SPECIFICATIONS

ENGINE

  • Design   1-cylinder 2-stroke engine, water-cooled, with reed intake and exhaust control
  • Displacement   249 cm³
  • Bore   66.4 mm
  • Stroke   72 mm
  • Starting aid   Kickstarter and electric starter
  • Transmission   6 gear, claw shifted
  • Engine lubrication   Mixture oil lubrication
  • Primary ratio   26:72
  • Secondary gear ratio   14:50 (13:50)
  • CoolingLiquid    cooling system
  • ClutchWet multi-disc clutch DDS / Brembo hydraulics
  • Ignition systemContactless, controlled, fully electronic ignition system with digital ignition timing adjustment, type Kokusan

CHASSIS

  • FrameCentral tube frame made of chrome molybdenum steel tubing
  • ForksWP Suspension Up Side Down 4CS
  • Shock absorberWP Monoshock with linkage
  • Suspension travel Front 300 mm
  • Suspension travel Rear 330 mm
  • Brake system FrontDisc brake with four-pot brake caliper
  • Brake system RearDisc brake with one-pot brake caliper, floating brake discs
  • Brake discs – diameter Front 260 mm
  • Brake discs – diameter Rear 220 mm
  • Chain 520 X-Ring
  • Steering head angle 63.5°
  • Wheel base 1,482±10 mm
  • Ground clearance (unloaded) 355 mm
  • Seat height (unloaded) 960 mm
  • Total fuel tank capacity  approx.11 l Unleaded premium fuel (95 octane), mixed with 2-stroke engine oil (1:60)
  • Weight without fuel  approx.104.4 kg
